Scag
Jackal MAKING
NEW TRACKS Making
new tracks. Breaking new ground. Making a stand for more diverse profitability.
However you say it, the new Scag® Jackal™ stand-on mini skid
steer is doing it. Hit the ground running with this bold workhorse, and
dig into untapped productivity and profit-making potential. 3 engine
options: Kubota 24.8hp diesel, Yanmar 24.7hp diesel or a Kohler 24.7hp
diesel.
Drive System
Type
Hydro drive w/ two variable displacement
pumps & two cast-iron high-torque wheel motors for independent control
of each drive track
Track
Dual 7" or 9"-wide, reinforced tracks
included; 5.5 psi of ground pressure. Easy-change capability between narrow
(7")
and optional wide (9") tracks.
Hydro pumps
Two 18cc pumps with dump valves for movement
without running engine; one cooling fan
Drive wheel motors
Two Parker Torqmotor TGK series 360 cc
LSHT cast-iron high torque wheel motors
Easy-to-use joystick drive control lever
via pilot servo
Deep Valves
Allows for movement without engine running
Forward Speed Range
0 up to 4.0 mph
Chassis
Fuel Tank
12-gallon total capacity (45.4 L); dual
6-gallon tanks
Ground Clearance
7.5" of clearance
Lift System/Loader
Arms
Type
Hydraulic-powered radial lift loader arms
with universal-type mounting system to accept a wide variety of buckets
and other attachments
Control
Easy-to-use joystick control lever
Lift Capacity
1,125 lb maximum
Tip Capacity
3,142 lb maximum
Hinge Pin Height
83"
Maximum Bucket Angle Rollback
25°
Bucket Dump Angle
40°
WORK WITH CONFIDENCE A machine that’s designed to keep you in control with an ultra-low
center-of-gravity, narrow stance, and shorter length—optimizing its overall
maneuverability and stability, even when navigating narrow and tight spaces.
GET THE JOB DONE Featuring a 1,125-lb. lift capacity with a 3,142-lb. tip capacity,
the Jackal has a 83” hinge pin height that delivers a high lift and dump
point to help you reach into large dumpsters, containers and truck beds.
And with a 15 GPM auxiliary hydraulic flow at 3000 psi, it has the power
and efficiency for whatever challenges await you.
POWER YOU CAN DEPEND ON With productive ground speeds up to 4 mph, you’re able to work across
job sites with maximum efficiency.
IN CONTROL FOR THE JOB AHEAD Easy-to-use, ergonomic joystick drive and bucket controls provide incredible
ease-of-use and simple operation.
DIMENSIONS
Length
86" w/o front attachment
112" with front bucket
Width w/7" tracks
Track width 35.5"
Bucket width 36"
Height
56.5"
Weight
2952lb w/o attachment
3127lb with front bucket
STAY WORKING LONGER Ready to work from sunrise to sunset, the Jackal is equipped with dual
6-gallon tanks that both feature large filler necks and fuel gauges for
operator convenience.
Stihl cutoff saws
TS420 There are no easy jobs in the construction and demolition business,
but when it comes to cutting performance there is one easy choice: the
14” TS 420 STIHL cutquik cut off machine.
This STIHL cutquik cut off machine, one of the best we’ve ever built.
We’ve followed up the legendary and number one worldwide-selling
TS 400 with a cut off machine that is even better. This new TS machine
can help you work longer, and keep on schedule, thanks to patented advancements
in technology and renowned STIHL innovation.
Only $1,289.99
14"
TS 420 STIHL Cutquik
DISPLACEMENT
66.7 cc (4.07 cu. in.)
ENGINE POWER
3.2 kW (4.4 bhp)
WEIGHT
14" wheel guard: 21.2 lbs.
ENGINE SPEED
9,500 rpm (Elec. gov)
MAXIMUM SPINDLE SPEED
5,350 RPM
MAXIMUM CUT DEPTH
125 mm (4.9”)
Same as the TS 410 but with a 14"
wheel size.
TS500i Abrasive cutting just got more cutting-edge. STIHL introduces another
industry first with the TS 500i Cutquik® cut-off machine. The
first handheld outdoor power tool to offer an electronically controlled
fuel-injection system. This system increases power and performance over
15% while remaining lightweight and well-balanced. The fuel injection system
makes starting easier and more reliable by eliminating the choke. Just
set the switch to on, prime and pull. Balanced, lightweight, powerful and
fuel-injected, this 14” cut-off machine is designed for superior balance
and handling during your toughest jobs. And just like a powerful sports
car, you will be impressed with the amazing acceleration of this machine,
getting you back to speed faster than you thought possible. The STIHL TS
500i also features a high-efficiency engine with low exhaust emissions
and optimal torque throughout its RPM range. Its Electronic Water Control
(EWC) allows for easy water flow adjustment while cutting and its X2 air
filtration system maintains an incredible 99.96% cleaning efficiency. This
machine has it all, so very little can stand in your way.
Only $1,649.99
14"
TS 500i STIHL Cutquik
DISPLACEMENT
72.2 cc (4.41 cu. in.)
ENGINE POWER
3.8 kW (5.1 bhp)
WEIGHT
10.2 kg (22.5 lbs.)
ENGINE SPEED
9,000 rpm (Elec. Gov.)
MAXIMUM SPINDLE SPEED
5,350 rpm
MAXIMUM CUT DEPTH
125 mm (4.9 in.)
Weight includes water attachment
and guard.
TS700 The TS700 is the most advanced STIHL cutquik ever produced. It
features the amazing X2 long term air filtration system for extended
service intervals and a powerful, fuel efficient engine that gets the job
done. The TS700 is lightweight, well balanced and features a brand
new 5 point, dual element vibration control system for exceptional
operator comfort. Loaded with innovative features like the semi automatic
belt tensioner, the TS700 is the right choice for
demanding professionals.
Only $1,699.99
14"
TS 700 STIHL Cutquik
DISPLACEMENT
98.5 cc (6.0 cu. in.)
ENGINE POWER
5.0 kW (6.7 bhp)
WEIGHT
25.6 lbs.
ENGINE SPEED
9,800 RPM
MAXIMUM SPINDLE SPEED
5,350 RPM
MAXIMUM CUT DEPTH
(5")
With the X2 long term filtration
system,
this machine is designed for extended
service cutting.
TS800 Just like the TS 700, the TS 800 with the X2 long-term filtration system
is designed for extended cutting service. This machine does the job of
other large walk-behind machines with a deep cutting 16" wheel.
Only $1,799.99
16"
TS 800 STIHL Cutquik
DISPLACEMENT
98.5 cc (6.0 cu. in.)
ENGINE POWER
5.0 kW (6.7 bhp)
WEIGHT
28.7 lbs.
ENGINE SPEED
9,000 RPM
MAXIMUM SPINDLE SPEED
4,600 RPM
MAXIMUM CUT DEPTH
(6")
Does the job of large walk behind
machines.
Deep cutting 16" wheel.
Stihl Rock Boss - Concrete Chainsaw
GS461 When you need to cut deep into concrete, reach for the Boss –
the STIHL GS 461 Rock Boss®. This revolutionary concrete cutter changes
the game with enhanced performance that cuts up to 15.7” deep into concrete,
reinforced concrete (with rebar up to ½ inch), cinder blocks, masonry
bricks, asphalt and soft stone. And it does all of this in a compact, lightweight
package that is easy to maneuver and transport.
It’s a great addition to your construction site when you need to get
serious with concrete materials. And because it’s a STIHL, you know it
delivers excellent performance. GS 461 Rock Boss® features include
a low exhaust emission engine, HD2 heavy-duty air filter, advanced water
controls, low vibration, and our exclusive Diamond Abrasive Saw Chain.
Only $2,449.99
- 16"
GS 461 STIHL Rock Boss
DISPLACEMENT
76.5 cc (4.67 cu. in.)
ENGINE POWER
4.3 kW (5.8 bhp)
WEIGHT
16.8 lbs.
FUEL CAPACITY
26.4 oz
DIAMOND ABRASIVE CHAIN
3/8" 36 GBM
GUIDE BAR LENGTH
(16" or 18")
STIHL ROLLOMATIC® G
A powerful concrete cutter designed
for deep cutting and square corners – perfect for construction and renovation
projects.
Stihl Smaller Auger and Drill
BT 45 Earth Auger For large landscaping projects like mass plantings,
ditch the shovel and pick up the BT 45 earth auger from STIHL. Its lightweight
gasoline-powered engine goes where electric models don’t, so you can dig
in remote areas. Ideal for mass flower plantings or deep root fertilization,
this small, compact landscaping auger helps you work large amounts of soil
more quickly with less fatigue. A primer bulb and throttle lock make the
auger easy to start, while an anti-vibration system and ergonomic design
make it easy to operate.
NOTE: The BT 45 earth auger is not for rocky,
compacted soil or drilling large post holes.
Only $549.99
plus
the bit
Small,
specialized auger for mass flower plantings, small posts, sign holes, or
deep root fertilization.
Earth Auger Bits
BT 45 Drill The STIHL BT 45 wood boring drill's lightweight,
gasoline-powered engine is portable and goes just about anywhere outside.
Accepting a wide range of bit sizes, it is ideal for use in building or
repairing wooden docks, bulkheads, fences, retaining walls and other structures
in locations that lack electricity access. This well-balanced drill features
a primer bulb and throttle lock for easier starting, as well as a compact,
ergonomic design for easy operation. Its two-speed gearbox includes a neutral
position as well as a reverse gear. It’s also great for pest control service
and tree service professionals, and with an optional kit, the BT 45 can
be used as a core drill for concrete work. For drilling performance, choose
STIHL.
Only $549.99
plus
the bit
Ideal
for building or repairing docks and bulkheads, fences, outbuildings, retaining
walls, and other structures where electricity is not available.
Stihl One Man Auger
BT 131 Earth Auger Professional User Get premium power and comfort without the premium
cost. The STIHL BT 131 auger features a fuel-efficient engine that delivers
high torque at low RPM. Its lightweight construction allows you to drill
with better control from an upright position. Our exclusive STIHL Quickstop®
auger brake technology automatically stops the auger if the bit becomes
snagged. Its advanced vibration dampening system and oversized hip pad
increase operator comfort – even during extended periods of use. The BT
131 is the ideal choice for professionals seeking an affordable auger with
trusted STIHL quality.
Only $799.99
plus
the bit
BT
131 Earth Auger
DISPLACEMENT
36.3 cc (2.2 cu. in.)
ENGINE POWER
1.4 kW (1.9 bhp)
WEIGHT
21.8 Ibs.
DRILLING GEAR SPEED
200 rpm
GEAR REDUCTION
47.5:1
Lightweight,
powerful one person auger with
exclusive quickstop brake.
Coming in 2025 Scag RC Extreme Slope Mower
PRODUCT SPECIFICATIONS
Drive System
Electric Drive (No PTO)
Drive Wheel Motors
OMNI
Producstive Speed Range
Up to 3.0 mph
Degree of Slope
45° without winch
Steering/Driving
Easy-to-use remote control
Number and Battery Type
3 (fixed to machine) - ALLIANCE I48-3.0
Total Battery Wattage
9 kWh
Productivity
Batteries power the machine from 100-20% for
approximately 1.5hrs after which the alternator generates power using the
37hp Vanguard engine to charge the batteries and run the machine.
Charge Time: Wall / Alternator
100% in about 7hrs / Charges up to 90% in
5-6hrs via alternator (dependent on cutting conditions)
Signal Range
1000 ft or line of sight (E-Stop on Signal
loss)
Remote Battery Life
10 hours
Cutting Width
52"
Electric Cutting Height Adjustment
3" to 12"
Thickness of Brush
Clearing heavy brush up to 1.5” in diameter
Engine Power
37 hp Vanguard Big Block V-Twin EFI
engine with ETC with Oil Guard
