Available in several model configurations to fit a wide range of professional
lawn maintenance needs. Compact size allows more units to fit on a single
trailer.
-
Up to 11.6 MPH forward speeds and up to 5 MPH reverse speeds keep productivity
at a maximum.
-
52", 61" and 72" Velocity Plus™ Cutter Deck deliver an immaculate quality-of-cut.
Three year limited warranty on the cutter decks.
-
Spacious operator platform with coil suspension delivers a smooth the ride
and reduces operator fatigue.
-
Wide operator platform is made from heavy gauge steel with extruded star
pattern for no-slip footing. Platform is wide and unobstructed.
-
Kawasaki FX1000 series engines are commercial-grade and feature canister
air filters, electronic fuel injection, pressurized oil lubrication and
much more.
-
The Vanguard series engine are commercial grade, feature canister air filter,
electronic fuel injection, dual ball bearing supported dtnamically balance
crankshaft, pressure lubrication and much more.
-
The Kohler EFI (electronic fuel injection) engine is incredibly powerful
and an efficient powerhouse. The engine will start easier and is more fuel
efficient than carbureted models, reducing overall operating cost.
-
Scag tough main frame construction delivers solid strength and ensures
years of trouble-free service. The main frame was designed for strength
and longevity.
-
Ogura GT 3.5, 250 ft.lb and the PTO clutch brake engages and stops the
cutter blades smoothly and safely.
-
Adjustable air gap ensures long component life.
-
Convenient, full-featured instrument panel has Tiger Eye: Advanced On-Board
Monitoring System, ignition key, PTO switch, throttle and choke. The fuel
gauge is located on top of the fuel tank, right next to the instrument
panel for easy viewing.
-
Extra- large Operator Comfort Cushion allows for comfortable operation,
hour after hour. Cushion is removable without tool for easy access to hydraulic
and engine compartment.
-
Large diameter, padded steering control levers are very comfortable and
easy on your hands. The hand force required to control the V-Ride XL is
minimal and the lever action is extremely smooth.
-
Heavy-duty blade drive spindles provide reliable performance season after
season. The Scag spindle is more than tough enough to handle the high horsepower
and torque requirements of this mower. Three year limited warranty on the
spindles.
-
Dual 16cc hydraulic pumps and dual 18ci cast iron, high-torque wheel motors
provide smooth, positive and reliable power to the drive wheels.
-
12 gallon fuel tank keeps you in the field cutting grass. Fuel tank features
a fuel level gauge and an extra large filler neck for easy filling.
-
Interlocked parking brake prevents the mower from being driven with the
brake on, stopping premature brake wear.
-
Easily adjust cutting heights with the convenient, easy to lift hand lever.
Wide range of adjustment from 2" to 6" in 1/4" increments. Auto-lock in
transport position with a simple thumb release.
-
Deck leveling adjustment brackets at all four corners of the deck allows
for easy in-the-field deck leveling and pitch adjustment.
-
Tri-Plate cutter deck top is incredibly strong. .485" deck top thickness
from three separate layers of steel (7ga., 10ga, and 11ga.)
-
"Split-Steel" pulleys are used on load carrying areas like the cutter deck
spindles and pump drive systems. Split steel pulleys are stronger than
cast iron or stamped pulley designs. Our pulleys are strong for long life
and lightweight for reduced inertia and decreased wear on the cutter deck
drive system.
-
No plastic pulleys - Some [other brands] actually use plastic pulleys on
their mowers. Not Scag. All Scag pulleys are made from metal. Plastic is
for toys.
-
Tapered locking hubs are used on spindle shafts and pump input shafts for
easy pulley removal and service for years to come.
-
High-quality bearings and bearing debris guards on idler pulleys ensure
long, reliable service.
-
Self-adjusting belt systems effortlessly keep belts in constant adjustment
for maximum life and minimum maintenance.
-
Tapered roller bearings are utilized in the front caster wheel axles and
caster yoke pivots for durability and reduced maintenance.
-
Extra-large drive tires ensure better traction, less turf tearing and easy
curb climbing.
-
Flat-Free front caster tires eliminate the downtime associated with flat
tires caused by debris, thorns, etc.
-
Four tie-down points are built-in on the front and rear of the mower (2
front, 2 rear) for fast and convenient loading and unloading on trailers.
-
Custom-Cut Baffle allows you to customize the cutter deck to your individual
cutting conditions.
-
Simple, easy to service, neutral and tracking linkages. It's the same design
that we use on other Scag riding mowers. No cable systems or complicated
bracketing. Straightforward designs with proven reliability.
-
User-friendly mower design allows access to the engine and filters, for
easy maintenance. Engine oil drain hose included.
-
Solid hillside stability due to a low center-of-gravity, large tires and
a wide stance. There is also a dual wheel kit availlable for added
stability.
-
Marbain cutter blades stay sharp longer for reduced maintenance.
-
High quality electrical components such as switches, wiring and harness
looms are used throughout the Scag mower line for dependable service.
-
Sealed fuse holder keeps the elements out to help prevent corrosion and
electrical issues.
-
Fuel tank shut-off and fuel gauge are located on top of the tank, near
the instrument panel for easy access and viewing.
-
The Scag "Simply the Best" commercial warranty stands behind you and your
mower for years of profitable service.
SCAG V-RIDE XL MOWER MODELS
/ ENGINE AND CUTTER DECK COMBINATIONS
| SVRXL-52V-38FX-EFI: 52" Velocity Plus™
Cutter Deck, 38hp Kawasaki FX1000 air-cooled EFI engine |
| SVRXL-52V-40BV-EFI: 52" Velocity PLus™
Cutter Deck, 40hp Vanguard EFI air-cooled engine |
| SVRXL61V-38CV: 61" Velocity Plus™ Cutter
Deck, 38hp Kohler Command EFI air-cooled engine |
| SVRXL61V-38FX-EFI: 61" Velocity Plus™
Cutter Deck, 38hp Kawasaki FX1000 air-cooled EFI engine |
| SVRXL61V-40BV-EFI: 61"
Velocity Plus™ Cutter Deck, 40hp Vanguard EFI air-cooled engine |
| SVRXL72V-38FX-EFI:
72" Velocity Plus™ Cutter Deck, 38hp Kawasaki FX1000 air-cooled EFI engine |
| SVRXL72V-40BV-EFI: 72"
Velocity Plus™ Cutter Deck, 40hp Vanguard EFI air-cooled engine |
SCAG V-RIDE XL PRODUCT
DIMENSIONS
| V-Ride XL Product Dimensions: |
52" V-Ride XL |
61" V-Ride XL |
72" V-Ride XL |
| Length: |
70.5" |
73.5" |
76" |
| Tracking Width: |
51.5" |
53.2" |
53.2" |
| Width (chute down): |
65.25" |
73.5" |
83" |
| Width (chute in transport position): |
53.75" |
62.75" |
73.75" |
| Weight: |
1150 - 1179 lbs. |
1201 - 1266 lbs. |
1264 - 1293 lbs. |
| Overall Height: |
47.75" |
47.75" |
47.75" |
|
|
Suspension Platform |
Extra Large Comfort Cushion |
Ogura Adjustable PTO Clutch |
High Strength Solid Frame |
 |
Full Featured Instrument Panel
Easy Adjust Cutter Deck Lift
Dual (16cc) Hydraulic
Pumps |
